Antibacterial and Antiviral adhesive films activated by PYLOTE technology

Description
Specifications

BECAUSE HYGIENE IS MORE IMPORTANT THAN EVER

Building on its existing offer of adhesive decorative laminates and protective films for the cabin, ADHETEC has integrated to the coating of its cabin products a natural and non-toxic antimicrobial technology developed by PYLOTE, a long time expert in mineral, to ensure a safe and clean environment for passenger well-being on board. The antimicrobial range of foils enables the almost timeless neutralization of bacteria, viruses, mold and yeast by contact to the surface. Airlines can choose among a selection of products, printable or clear, depending on the surfaces to protect. The printable products will offer valuable branding and advertising opportunities to the passengers in the cabin.

PROTECT, COMMUNICATE & ENHANCE

  • Contribute to the protection of cabin parts: the films increase their durability
  • Proven long term antimicrobial efficiency of the surface, including Human Coronavirus
  • Destroys >99.999% of bacteria & >99.9% of viruses by direct contact: does not release any volatiles
  • Natural antimicrobial technology, user friendly
  • Standard cleaning methods (wipe as usual)
  • Easy installation (die cuts) and removal during maintenance operation

Download the product infosheet

DESCRIPTION UNIT VALUE METHOD

Adhesion system of the product pattern

NA

Grade 0

Cross-cut test 1mm

Adhesive strength

N/cm

3to5

Peel strenght 180° at 300mm / min 24h after application on steel

Antimicrobial and antivirus*

NA

Pass

Escherichia coli ATCC 8739 Coronavirus humain 229E ISO 22196 / JIS Z 2801 ISO 21702

Humidity resistance

NA

No damage: no adhesive residue

ISO 9142
Climatic cycle: 48h
15h +/- 1h at 40°C and 95% HR 3h +/- 1h at -20°C
6h +/- 1h at -70°C
15h +/- 1h at 40°C and 95°C HR 3h +/- 1h at -20°C
6h +/- 1h at 70°C

Chemical resistance

NA

No damage: no delimination, no effect on readability

Immersion 168h at 23°C in cola Immersion 168h at 80°C in coffee Immersion 1000h at 23°C in water Immersion 168h at 23°C in the cleaning product AMS1550 TG3000 50 rubs with isopropylic alcohol 20 rubs with acetone

Scratch resistance

NA

6N necessary for light scratch mark

Scratch test with a sclerometer 1,2,4,6,8,10,16N

Rub resistance

NA

No damage

Rub test with a plynometer: 50 rounds trip

Impact resistance

NA

No damage, just light mark

Height of fall: 1000mm Diameter of the ball: 20mm

Vertical flammability 60s

NA

Pass on Alu 1mm Pass on HC 9,4mm

FAR25.853 Appendix F, Part I, (a)(1)(i)

*Embedding the natural antimicrobial protection by Pylote: micron-sized mineral additives are mixed in our coatings. The antiviral and antibacterial combined action of the microspheres operates by contact with the surface of parts and equipments. It is the result of a reaction between moisture, air and the surface containing the antimicrobial treatment, killing germs. The microspheres are neither consumed nor extracted from the surface but kept active in the surface they have been integrated into.
The technology is natural and does not release toxic volatiles in the air, is safe for all, even small children.
