Gas, Air and Watertight Concrete Infill Covers
Company | Mascot Engineering |
---|
Images
Mascot’s Concrete Infill Covers are the most popular Gastight Access Cover and remains the staple in the Mascot Engineering range.
Rectangular and square covers have carefully machined horizontal and vertical faces of the iron cover and frame components to produce a cover assembly that doesn’t rock when traffic passes over. Designed with high performance ribbing for infilling with concrete or pavement material that is sealed once infilled, each product is designed in accordance with the standards and load tested to the requirements of EN124.
Mascot Engineering’s range of Covers are available as C250, D400 and F900.
Ductile Cast Iron
Compliant to load ratings C250, D400 and F900 as per EN 124
Sizes available in mm:
Clear Opening
300×300
450×450
450×600
600×750
600×900
750×600
750×750
900×600
900×750
900×900
1200×600
1260×1200
1260×450
600×450
Tested for gas, air and watertightness.
Boltdown and security systems available
Covers supplied with lifting keyholes and plugs
Units are coated in bituminous paint complying with BS3416 type II
