GP 28V DC SF 28V DC Ground power supply cable - Dymmetrical Flex

Description
Specifications

For the application as fixed supply cable with optimised installation or for a flexible hand-held application without elevated mechanical stress for example mobile GPUs.

Outstanding features

  • low capacity insulation
  • extremely flexible and smooth handling
  • also usable as supply cable at the aircraft itself
  • very good installation in narrowest spaces
  • good resistance characteristics also against wear and tear

Technical Data:

  • Voltage: 28V DC
  • Testing voltage: core/core 600 V
  • Min. bending radius: fixed laying: 4 x d flexible application: 6 x d
  • Temperature range: fixed laying: -40/+70 °C flexible application: -20/+70 °C
  • Oil resistance: acc. to internal standard
  • Absence of harmful substances: acc. to RoHS directive of the European Union
