Multi-Lateration (M-LAT) Radar System – Advanced Air Traffic Control Surveillance
| Company | Easat Radar Systems Ltd |
|---|
Images
Improve your Airspace surveillance and ground movement monitoring with EASAT’s state-of-the-art Multi-Lateration (M-LAT) Radar System—a highly accurate and cost-effective solution for real-time aircraft positioning and tracking. Designed for airports, air navigation service providers, and defence applications, this advanced system provides precise aircraft identification and movement tracking using time-difference-of-arrival (TDOA) technology, ensuring seamless integration with modern air traffic control (ATC) systems.
Ensure safe and precise aircraft landings with EASAT’s state-of-the-art Precision Approach Radar (PAR)—an advanced air traffic control system designed to provide high-accuracy landing guidance in all weather conditions. Engineered for military airbases, civil airports, and emergency landing sites, our PAR system delivers real-time, high-resolution tracking of aircraft position, azimuth, elevation, and range, ensuring safe landings even in low visibility and adverse weather.
Key Benefits & Features
✔ High-Precision Aircraft Positioning – Uses time-difference-of-arrival (TDOA) technology to calculate exact aircraft locations with sub-meter accuracy.
✔ Enhanced Surveillance for Air & Ground Operations – Monitors aircraft in en-route, terminal, and airport surface environments, improving airspace and ground safety.
✔ Seamless ATC Integration – Compatible with Mode S transponders, ADS-B, and existing radar networks, ensuring real-time surveillance data for air traffic controllers.
✔ Cost-Effective Alternative to Traditional Radar – Provides high-accuracy aircraft tracking with lower infrastructure and maintenance costs compared to conventional radar systems.
✔ Scalable & Flexible Deployment – Ideal for large airport hubs, regional airports, and military airbases, adapting to diverse operational needs.
✔ Reliable in All Weather Conditions – Functions effectively in fog, rain, and low-visibility conditions, ensuring continuous operational efficiency.
✔ Secure & Interference-Resistant – Minimizes jamming risks, ensuring robust and secure air traffic surveillance.
Optimized for Safe & Efficient Air Traffic Management
EASAT’s Multi-Lateration (M-LAT) Radar System enhances air traffic control accuracy, reduces congestion risks, and improves situational awareness, making it a trusted choice for civil and military aviation authorities worldwide.
Upgrade to Next-Generation Surveillance Technology
Ensure precise and efficient air traffic surveillance with EASAT’s Multi-Lateration (M-LAT) Radar System. Contact us today at www.easat.com to discover how our cutting-edge radar solutions can optimize your airspace and airport operations.
| Parameter | Ground Station (GSR) |
Ground Station (GST) |
Reference Ground Station (RGS) | ||||
| Mode | Receive-Only | Receive and Transmit | Receive and Transmit | ||||
| Functions | Detects, Time Stamps, Processes Target Messages |
Detects, Time Stamps,
Processes Target Messages Elicitation of Replies from Targets using 1030 MHz Interrogations |
Detects, Time Stamps, Processes Target Messages
Distribution of Reference Timing Information throughout the System via 1090 MHz Signals |
||||
| Main Components | 1090 MHz Receiver
UPS/Battery Backup Network Equipment |
1090 MHz Receiver
1030 MHz Transceiver UPS/Battery Backup Network Equipment |
1090 MHz Receiver
1030 MHz Transceiver UPS/Battery Backup Network Equipment |
||||
| Typical Power Consumption | 25 W | 100 W | 50 W | ||||
| Number of
Data Output Interfaces |
2 x Ethernet
Network Technologies for Further |
||||||
| Autonomy | > 1 Hour | ||||||
| Operation
Temperature |
-40 °C … +55 °C | ||||||
| Operation
Humidity |
95% Non-Condensing | ||||||
| Enclosure
IP Rating |
IP66 robust
outdoor enclosure |
||||||
| MTBF | > 20,000 Hours | ||||||
| MTTR | < 30 Min | ||||||
| Availability | 0,9999 | ||||||
| Receiver Sensitivity | -91 dBm for Mode A/C/S | ||||||
| Update Rate | Not more than 1 sec | ||||||
| Horizontal Position Accuracy on the Runways | Within 7.5m with confidence of 95%
Within 12m with confidence of 99% |
||||||
| The maximum delay in the processing of informant | Not more than 1 sec | ||||||
| Number of Simultaneously Processed Targets | Not Less than 250 | ||||||
