Precision AC for Airport Computing Room
| Company | Shenling Airport Solutions |
|---|
Images
As a climate control expert, Shenling offers a range of Precision Air Conditioners (PACs) designed to deliver highly controlled environmental conditions for sensitive equipment in airport computing rooms and operations towers. Unlike standard air conditioners, which cool general spaces, PACs maintain precise temperature and humidity levels, ensuring tight tolerance control for critical environments.
Key features of Shenling PACs
- High Efficiency
In-room direct expansion PAC: Available with on/off or DC inverter compressor options.
In-row direct expansion PAC: Equipped with a full DC inverter compressor.
High-efficiency EC fan: Ensures low noise and reduced operating costs.
Electronic expansion valve: Offers a wide adjustment range and precise control.
- Flexible Configuration
Optional centralized condenser: Space-saving design.
Optional outdoor spray system: Enhanced cooling efficiency.
Optional fluorine pump-free cooling mode: Energy-efficient operation.
- Module Design
Modular design, flexible installation.
- Smart Control
7-inch touch screen for easy operation.
Standard RS485 port with Modbus protocol.
Smart group control with load balancing.
Optional SNMP protocol for advanced monitoring.
Supports control of up to 32 units in a group.
- Humidifier
Standard wet film humidifier: Low operating costs.
Energy-efficient and easy to maintain.
Optional electrode and infrared humidifiers for enhanced performance.
In-room Direct Expansion Precision Air Conditioners(On-Off)
Air Discharge Direction: Upflow, Downflow
Cooling Capacity: 26.4-45.7kW
Sensible Cooling Capacity: 24.5-41.6kW
System Quantity: Single
Airflow: 7500-12000m3/h
Dimensions: 900(W)*1000(D)*1980(H)mm
Net Weight: 355-390kg
In-room Direct Expansion Precision Air Conditioners(DC Inverter)
Air Discharge Direction: Upflow, Downflow
Cooling Capacity: 25.1-50.5kW
Sensible Cooling Capacity: 24.2-45.8kW
System Quantity: Single
Airflow: 9000-13000m3/h
Dimensions: 1100(W)*1000(D)*2000(H)mm
Net Weight: 320-340kg
In-room Chilled Water Precision Air Conditioners
Air Discharge Direction: Upflow, Downflow
Cooling Capacity: 43.7-205.3kW
Sensible Cooling Capacity: 34.2-156.8kW
System Quantity: Single
Airflow: 8000-37500m3/h
Dimensions: 900(W)*1000(D)*1980(H)mm
Net Weight: 320-920kg
