Truck-mounted Airport Sweeper

Description
Specifications

The AS 660 is an extremely powerful and efficient truck-mounted sweeper that is specially designed and perfectly matched to meet the needs of airports. With its rear suction unit and high suction power extending across the entire width of the vehicle, the sweeper removes FOD (Foreign Objects Debris), leaves and dirt, plus liquids such as glycol or water, easily from stand and apron areas. Sweeper operation is fully integrated into the super-efficient and highly acclaimed ES control panel, enabling easy and straightforward control whilst driving.

  • AS660 – Specification
  • Hopper volume 7 m³
  • Disc brush diameter 550 mm / 650 mm / 750 mm
  • Sweeping width 1,200 mm
  • Sweeping width with suction nozzle and roller brush 2,350 mm
  • Roller brush diameter 400 mm
  • Roller brush length  1,300 mm
  • Type of drive             Hydraulic motor
  • Max. air flow rate (free flow)  18,000 m³/h
  • Speed 2.1 1/min
  • Total water volume 1,600 l
  • Drive system – auxiliary engine
  • Torque     260
  • Speed range              1,600 1/min
  • Engine type               Deutz TD 2.9 L04
  • Displacement           2,900 cm³
  • Speed range              1,600 1/min
  • Hydraulic tank volume             130 l
  • Transport speed       90 km/h
  • Empty weight of the basic unit approx.  4,250 kg
