VHF Ground Transceiver

Description
Specifications

With a smart and compact format, the GT6201 single block VHF radio is the ideal solution for air traffic control towers looking for a cost-efficient main or backup radio to be integrated into existing ATC desks or consoles. Available also with a specific mounting kit for vehicle integrations.

Designed for operations at airfields and airports in a very demanding environment, the GT6201 offers latest technology and support all frequency channels in the aeronautical frequency range, adjustable in 25 kHz steps as well as in 8.33 kHz steps. With an output power of 6 W or 10 W, the transmitter is strong enough for medium range communications, ensuring a low cost of ownership for the customer.

  • 6 W or 10 W RF-power variants
  • Power supply: 10-30 VDC or 12/24 VDC battery
  • Dual scan function (monitoring two frequencies during TX/RX)
  • Channel spacing: 25 and 8.33 kHz
  • Frequency range: 118.000-136.990 MHz
  • Selectable and adjustable squelch levels
  • Parameter setting via user menu
  • 99 free editable memory channels
  • Non-volatile memory
  • Emergency mode
  • 4 fully configurable audio outputs
  • Compliant with ETSI standards and type approved for ATM applications
  • Reduced installation footprint
  • Low weight
  • Robust and field-proven design
  • No forced cooling
  • No ventilation slots
  • Maintenance-free
  • User-friendly HMI
  • Large, clear and dazzle-free LCD display
  • Extensive setup possibilities
  • Vehicle mounting kit available
