400Hz Line voltage regulator - LVR
| Company | Avicorp Middle East FZCO |
|---|---|
| Product code | APOJET LVR 90 |
Images
Description
Specifications
Line Voltage Regulators will compensate for voltage drop between the central 400Hz system and the aircraft service pits. The LVR’s are rated at 90kVA from PF 0.8 to 1.0 continuous and will provide up to 12% voltage boost. The compensation is both programmable and voltage sensing and either will compensate voltage phases individually.
Voltage range: 3 x 200 V/115V ± 15 %
Frequency: 400 Hz 5%
Line Current :577A
Output:
Frequency: 400 Hz ± 0.1 %
Voltage : 3 x 200/115 V
Line Current :260A
