ThruScan s27-i Security Walk Through Metal Detector
| Company | Elektral Elektromekanik A.S. |
|---|---|
| Product code | 869755498132 |
Images
Description
Specifications
- International norms (NILECJ-0601 L1-5 / NIJ 0601.02 Small Object Sensitivity 60529, EN 60068, EN60950 Class1 / IP44 ) In conformity with ECAC DOC 30 Standard 2, CE European Union Norms and produced under ISO 9001: 2015 QMS
- Certified in Compliance to EN 61000-6-3, EN 61000-6-1 regulations and in compliance with DIRECTIVE 2002/95/EC (restriction of the use of certain hazardous substances in electrical and electronic equipment)
- Multi-Zone – 27 Detection Zones (Up/Middle/Down and Left/Middle/ Right and Front/Rear)
- Separate Sensitivity Settings for Different Detection Zones
- Standard Preset JAILHOUSE / AIRPORT / MILITARY / POLICE PREMISES / SHOPPING MALL Security Levels
- Whilst Normal Operation, displays IN/OUT Counters and Security Level on 64×128 GLCD
- Capable to Detect both Ferrous and Non-Ferrous Metallic Threat Objects Considered Dangerous by International Security Authorities.
- Displays Location of the Detected Metal Objects with Continuous LED Zone Indicators on Both Side Panels from top to bottom
- Can detect when tested both individually and in combination.
- Detects all threat objects even concealed
- Random Alarm Feature
- Same Detection Capability from bottom to top
- Detects Metals regardless their orientation
- 20 sensitivity levels, 246 adjustable sensitivity steps at each, Preset NILECJ Sensitivity Program, – 10 Preset International Security Programs
- Automatic Frequency Selection Feature
- Metal Density-Mass, Signal Strength Display at 10-level-VU meter with green, yellow, red LED’s easily allows sight from distance
- Superior Discrimination, Pin Point target location identification with Graphical zone display on Control Unit. Auto Calibration
- Human Health friendly Very Low Frequency VLF technology
- Green/Red bicolor traffic through LEDs
- 60 Persons/Minute and LED Alarm Indicators
- Record Statistics of Operation Duration, number of visitors and alarms
- Real Time Environmental Magnetic Noise Level Display
- 10 Adjustable audio tones with 10 volume levels (enabling Mute Operation) Adjustable Alarm Duration
- IP65 (EN 60529) protection
- Five Digit Incoming/ Outgoing Alarm Counters (Visible/Invisible)
- Interference free Operation from other Electronic Devices and Does not effect other Electronic Equipment.
- Digital Pin Code and Mechanical Lock
- Automatic Failure Display Function with continuous self checking of key parameters (Built In test Equipment)
- Easy Programming and Display
- Languages: English, German, Spanish, Turkish and Arabic
- UPS enabling 2 hours operation without mains
- Built for 7/24 Continuous Operation
- 74 cm Net Passage Width and 200 cm Net Passage Height
- Interference free Operation at Middle Level Sensitivity of 10 cm Distance Constant Metals and 200 cm distance Moving Metallic Objects
- Installation and Operation without interference between two detectors up to a distance of min. 5 cm
- Audio-Visual alarms
- Micro-Processor Settings do not change when there is an electricity cut-off
- No interference with Storage Media, Flash Memories, CD, Diskettes and other electronic devices
- All Electronic Units are inside the Equipment. No external units.
- ABS Footers for sturdy placement and durable use.
- Operation Mode, Programming Parameters and Error Codes are Displayed on Wide 64×128 Characters Screen
- Optional -SCADA Software-Controlled remote data communication
- Optional REAL-TIME VIDEO PROSECUTION UNIT enabling recording of Alarmed Visitors Pictures/All Visitors pictures or video with Time-Stamp
- Optional IRDA (Pilot) Remote Control Unit
- Detection functions have been tested with ECAC/NIJ/TSA Test Kits and Certified
Technical Features:
- Operating voltage: 70VAC – 270VAC / 50Hz – 60Hz
- Power: 10W Stand By – 20W (Alarm)
- Ambient Temperature: -20°C to +70°C
- Package Dimensions (W x L x H):
- Box 1: 81 x 235 x 21 cm (65 Kg)
- Box 2: 43 х 81 х 27 cm (14 Kg)
- Gross Weight: 79 Kg
- Net Weight: 61 Kg
- Net Passage: 74 x 68 x 200 cm
- External: 85 x 68 x 220 mm
