Aurelis ATC – Hand microphone

Company Imtradex

Images

Description
Specifications

The base product in our Aurelis AirTalk® family. The device is equipped with a omni-directional microphone for best audio performance or with a dynamic microphone, depending on your choice of VCS communication system or VHF radio system.

The very grippy sealing running along the housing is especially designed to have a firm grip. A PTT button on the side is perfectly fitted for daily operations. The front side of the Aurelis is a highly flexible foil, which can be adjusted with multiple buttons for special operations, such as PTT, volume control or mute functions or LED’s.

On the backside is a clip for hanging on your workstation. The device is a very easy to handle microphone with flexible usability.

General Information

  • Dimensions: 115mm x70mm x 25 mm
  • Weight: 160g
  • Temperature range: -20°C to +60°C

Microphone

  • Working principle: Electret
  • Direction: Omni-Directional
  • Impedance: 1,2 kΩ (1kHz)
  • Frequency range: 50 Hz- 16 kHz
  • Sensitivity: -38 dB ± 3 dB at 1 kHz

Case

  • Material description: Bayblend T45 PG
  • Material definition: PC ABS
  • Flammability: UL94-HB
  • dielectric strength: 35 kV/mm
  • RoHS: Yes
