Dyba Slave Pallet 5ft
| Company | Dyba Tech B.V. |
|---|---|
| Product code | RS51 |
Images
Description
Specifications
Dyba Slave Pallet RS51 is a movable transport unit for handling ULDs. Slave Pallets are used for storage and the build-up and break down of ULDs in warehouses. This type of slave pallet can be moved by a standard 3 tons forklift with 2 forks.
Features / specifications:
- Suitable for ULD with base surface 60,4”x61,5” (e.g. AKE, AKH etc.)
- Operating height 208 mm
- Transfer deck surface: with gravity rollers Ø89
- Load direction: NEL (Narrow Edge Leading)
- Overall dimensions: 1720 x 1650 mm (l x w)
- Maximum load capacity: 2.000 kgs
- With 2 anti-slip walkway between rollers
- Can be picked up from 2 sides by the forklift
- Easy stackable when not in use
Options:
- Can be painted in any RAL colour
- Surface treatment: galvanised
- Extra ULD stops
- Customized forklift pockets dimensions
- Extra pockets forklift removal empty ULD
