Dyba Storage Rack Pallets
| Company | Dyba Tech B.V. |
|---|---|
| Product code | SR01 |
Images
Description
Specifications
Dyba Pallet Storage Rack is a heavy-duty steel construction in which you can store empty 10 ft pallets. After creating a stack by stacking rack SR51, you can store the pallets in the Storage Rack SR01 with a forklift. These racks facilitate sorting and storing pallets per airline. The storage racks consist of modular sections, which can be expanded to suit the capacity requirements.
Features / specifications
- Suitable for ULD with base surface 125”x96” (e.g. PMC)
- Capacity: 60 pallets
- Number of levels: 3
- Overall dimensions: 3540 x 2600 x 3000 mm (l x w x h)
Options
- Forklift pockets for single racks
- With roof
- With roof and side walls
- Expandable to 4 levels
- Expandable by connection with modular sections
- Storage 20 ft pallets (96”x238”)
- Can be painted in any RAL colour
- Surface treatment: galvanised
