LIMBOPLAST D480F
| Company | SWARCO LIMBURGER LACKFABRIK GmbH |
|---|---|
| Product code | 52D480F… (RAL-Classic Code) |
Images
LIMBOPLAST D480F airfield belongs to the group of solvent-free, multi-component, reactive systems. It´s especially suitable for airfield areas outside aircraft operating areas with intensive traffic impact by vehicles. It consists of two or more components, which form a duroplastic compound which cannot be thermally plastified thereafter. It is available in colors according to DIN 6171.
The material has been tested according to the requirements of EASA and ICAO Annex 14 regarding chromaticity co-ordinates, luminance factor and resistance to chemicals.
The material can be applied on aircraft operation areas. It must be checked in advance, whether flaked off cold plastic parts may be sucked into aircraft engines and cause damage. In case of doubt other products should be used.
LIMBOPLAST D480F is suitable for all bituminous surfaces and also concrete pavements (priming required). It can be applied with cold plastic application machines with open system / screed box technique or extruder technique.
Density approx. 1.84 kg/l +/- 0.06
Potlife: 5–10 minutes (depending on hardener quantity added and air, material and surface
temperatures; cf. “Table Potlife / Curing Times”!)
Solvent content: Solvent-free, must be applied without adding solvent
Solvent for cleaning: Special cleaner for marking machines Art.-No.: 3086
Storage stability: 6 months; unmixed in sealed original packaging and protected from frost and direct sun light!)
Trafficability / curing time:
Depends on the climatic conditions (cf. table “Potlife / Curing Times”). In general the marking’s
trafficability must be checked before exposing them to traffic impact.
BASt test reports (T – specifications) are laboratory results only
Standard packaging:
2-comp. D480F airport: Tin container with 10/15/25/40 kg filling weight, container
filling on request
3-comp. D480F airport: Tin container white filling weight 40 kg, non-reactive component
Tin container blue filling weight 40 kg, reactive component
Container – for reactive and non-reactive component;
Hardener powder: PE-bags – filling weight corresponds to cold plastic quantity and
mixing ratio
Liquid hardener: plastic cans – 20 kg filling weight
Attention: All hardener types are organic peroxides – they must be separately packaged,
transported and stored away from the cold plastic in special containers (special cartons and boxes).
Drop-on material: paper bags with PE-inlay – 25 kg filling weight.
Identification:
The regulations and instructions concerning appropriate transport, handling, storage, first aid
and measures, toxicology and ecology are stated in detail in our material safety data sheets!
The instructions stated on the product label and in the MSDS must be followed.
Processing temperature: min. + 5°C
Surface temperature: + 5°C to + 45°C
Relative humidity: max. 75% (dew point spreadsheet has to be regarded)
Layer thickness: Plain marking: 2–3 mm; Agglomerate: 1.5–3.0 mm
Theoretical consumption:
Plain marking: 3.7–5.5 kg/m² (2–3 l/m²) or approx. 1.84 kg/m² per 1.0 mm layer thickness
Agglomerate: 2.2–2.8 kg/m² (1.2–1.5 l/m²)
The actual consumption depends on the applied layer thickness, application technique and type
and state of the surface.
