LIMBOROUTE K828F

Density: approx. 1.63 kg/l +/- 0.04

Solid content:  min. 75%

Solid body: approx. 54.23%

Solvent content:  max. 25%

Thinner:
When needed add max. 2% thinner for high solid paint (Art.-No.: 3080) for optimizing spray
properties or add max. 2% thinner for high temperatures (Art.-No.: 3160) for optimizing bead
embedment. For cleaning of the machine and tools use Special cleaner for marking machines,
(Art.-No. 3086).

Storage stability: 1 year in unmixed, sealed original packaging, protected from frost and direct sun light.

Drying time / Trafficability:
The drying time stated in the BASt test report are laboratory values that may differ from field
conditions depending on climate (temperature, humidity, wind), material, layer thickness and
road surface. In general, the marking’s trafficability must be checked before exposing it to traffic
impact.

Standard packaging: tin containers of 6 / 15 / 40 kg filling weight, larger container on request
Drop-on material: paper bags with PE-inlay – 25 kg filling weight

Identification:
The regulations and instructions concerning appropriate transport, handling, storage, first aid
measures, toxicology and ecology are stated in our material safety data sheets! The instructions
stated on the product label and in the MSDS must be followed.

Processing temperature: min. +5°C

Surface temperature: + 5°C to 45°C
Relative humidity: max. 75 % (dew point spreadsheet has to be regarded)

Layer thickness /
Theoretical consumption:
Wet film thickness = Dry film thickness = Theoretical consumption
300 μm = 163 m = approx. 0.489 kg/m² (0.3 l/m²)
400 μm = 217 μm = approx. 0.652 kg/m² (0.4 l/m²)
600 μm = 325 μm = approx. 0.978 kg/m² (0.6 l/m²)
The actual consumption depends on the applied layer thickness and the type and state of the
surface.
