LIMBOROUTE 2-C K809F

Density: approx. 1.49 kg/l +/- 0.04 kg/l (with hardener)

Mixing ratio: base component 2-comp. K809F : hardener component (8623) = 20 : 1

Potlife: approx. 3 days

Solid content: min. 75%

Volume solid content: approx. 53.48%

Solvent content: max. 25%

Thinner:
If required add max. 2-5% Thinner for 2-comp. EP, Art. No.: 3130 for viscosity adjustment,
optimizing of spray properties and for cleaning of machine and tools.

Storage stability: 6 months (unmixed), in sealed original packaging;
protect from frost and direct sun light

 Drying time / Trafficability:
The drying time stated in the BASt test report are laboratory values that may differ from field
conditions depending on climate (temperature, humidity, wind), material, layer thickness and road
surface. In general the marking’s trafficability must be checked before exposing it to traffic impact.

Standard packaging:
2-comp. K809F : tin container of 35 kg filling weight
Hardener 8623: cans of 1.75 kg filling weight (corresponds with mixing ratio)
Drop-on material: paper bags with PE-inlay – 25 kg filling weight

Identification:
The regulations and instructions concerning appropriate transport, handling, storage, first aid
measures, toxicology and ecology are stated in our material safety data sheets! The instructions
stated on the product label and in the MSDS must be followed.

Processing temperature: min. +5°C

Surface temperature: +5°C to +45°C

Layer thickness / Theoretical consumption:
Wet film thickness = Dry film thickness = Theoretical consumption
300 μm = 160 μm = 0.45 kg/m² (0.3 l/m²)
400 μm = 214 μm = 0.60 kg/m² (0.4 l/m²)
600 μm = 321 μm = 0.89 kg/m² (0.6 l/m²)
The actual consumption depends on the applied layer thickness application technique and type
and state of the surface
