Snow sweeper P 21/S/SL/SXL
Towed snow sweeper with outstanding area output. Drive: Drawn Brush Width: 4.5 / 6 / 6.3 m
With its high-output engine, the P 21 is perfectly equipped for efficient snow removal. Its blower fan and brush are driven by two independent hydraulic circuits. The brush head is supported by the proven twin-wheel castor system to eliminate vibrations and minimise wear while sweeping. A blower nozzle mounted in front of the rear axle blasts air at speeds of 600 km/h, preventing any snow left on the ground from being flattened and compacted by the rear wheels. Available as a semi-trailer or three-wheel trailer, this machine is capable of clearing more than 185 000 m2
More power and a longer brush – that’s what sets the P 21S apart from the P 21. With its extra engine output and a 6 m or 6.3 m brush, the P 21S is ideal for use at large airports. This machine also runs smoothly without vibration due to the extremely rigid frame combined with the castor technology and parallelogram brush head suspension (with vibration damper). This extends the life of the brush bristles and increases efficiency and economy. The P 21S is simple to operate from the central control panel inside the cab. In automatic mode, the driver can concentrate fully on his snow clearing work, just controlling the brush swing and raising/lowering the sweeping units, either in combination or individually as required.
Powerful and reliable
ZAUGG AG EGGIWIL’s high-performance snow sweepers are engineered specifically for clearing snow and ice at airports. These state-of-the-art specialist vehicles featuring separate propulsion and auxiliary engines keep runways and taxiways clear for take-off and landing throughout the winter maintenance period. And they let you manoeuvre easily to clean surfaces in areas that are difficult to reach, like around air bridges.
All models come with an ergonomically designed, highly user-friendly control panel with simple displays and clear symbols, a few switches and a joystick. The snow sweepers are easy to operate from the central control panel inside the cab. In automatic mode, the driver can concentrate fully on his snow clearing work, just controlling the brush swing and raising/lowering the sweeping units individually.
Simple to operate
Special attention has been devoted to features for night operation and to the logical layout of all controls. With the turn of a key and a push of the engine start button and 3 switches for the main plough, brush and blower fan functions, the machine is ready to go. Using just a joystick, the driver can control the entire hydraulic motion system, pressing rocker switches to operate any of the main functions independently.
The blower fan and brush are driven by two independent hydraulic circuits. Another, separate circuit is provided to control all movements. All actions like opening the engine compartment and actuating emergency valve functions can be operated by an electric hydraulic pump when the auxiliary engine is switched off. With centrally located valves, solid tubing and simple hose guides, the hydraulic system has been engineered for maximum machine availability
|Snow sweeper P 21/S/SL/SXL|
|Blower nozzle in front of the rear axle|
|Engine output 260 KW or 315 KW (P 21S to SXL)|
|Electronic controller with error diagnosis program|
|Working width 4200 mm, alternatively 6000 mm and 6300 mm (P 21S to SXL)|
|Clearance speed > 50 km/h|
