RoadPakTM Airless Line Striping Range


With a modular design, Graco’s RoadPak systems can be customized to tackle any road and airport striping applications so you can improve your productivity and accuracy.

Designed to be mounted on different types of standard vehicles, the RoadPak solutions are delivered in 12 different configurations or in individual packages to allow optimum modularity for your specific needs. The RoadPak HD systems further extend this offering with double the output of the standard RoadPak and the ability to stripe with up to 5 or more guns.

Key benefits:

  • Heavy-Duty Modular Frame System:
    • Small frame size allows it to fit almost everywhere – from the back of a pickup or flatbed truck to the bed of a utility vehicle
    • Simple to add options you want in minutes
  • 1 or 2-Pump RoadPak System:
    • RoadPak is delivered as a 1- or 2-pump system allowing single or dual colour option
    • Step up to RoadPak HD to double your output up to 37,8 LPM
    • Optionally expand your system with extra pumps for other colours
  • Heavy-Duty RPS 2900 Hydraulic System: No-stall design and proven performer provides the productivity you get from Graco designed products

Accumulation tank for paint and bead guns up to 20 litres on the RoadPak HD system to support up to 5 paint and 5 bead guns

More Information:

  • Kohler® Power:
    • 18 HP (RoadPak)
    • 5 HP EFI (RoadPak HD)
  • Flow:
    • 9 lpm / 5 gpm (RoadPak)
    • 8 lpm / 10 gpm (RoadPak HD)
  • Bead Tank:
    • 204 kg / 450 lb up to 615 kg / 1350 lb
  • Optionally:
    • Slide-in Mounting Frame
    • RoadView HD Camera System
    • Simple Guide System
    • Gun Lift Winch Kit
    • Rear Seat Kit
    • Steerable Carriage
    • LazerGuide Systems
